2.5 Ton Outdoor Diesel Forklift | Economical Industrial Handling
2,500 kg Rated Capacity
The SCC25 provides a 2,500 kg rated capacity at a 500 mm load centre for common industrial and yard-handling applications.
Diesel Power for Outdoor Work
A four-cylinder 2,540 cc QC490BPG diesel engine, 60 L fuel tank, and pneumatic tires support regular outdoor material-handling operations.
3,000 mm Standard Lift Height
The standard 3,000 mm lift height supports common stacking, loading, and unloading requirements in industrial and logistics yards.
Practical Yard Dimensions
With a 1,160 mm overall width, 1,650 mm wheelbase, and 2,480 mm outside turning radius, the SCC25 is configured for movement around trucks, storage lanes, pallets, and material stacks.
The SCC25 diesel forklift is an economical 2.5 ton forklift for routine outdoor material handling. It is designed for industrial yards, logistics operations, building-material storage, and other suitable work areas where diesel power and pneumatic tires are required.
With a 2,500 kg rated capacity at a 500 mm load centre and a 3,000 mm standard lift height, the SCC25 can handle common loads such as pallets, packaged goods, building materials, and general industrial materials. Actual capacity depends on the load centre, attachment, mast configuration, and applicable load chart.
The forklift has a listed 19 km/h unloaded travel speed and 20% maximum gradeability when laden. Its 1,160 mm overall width and 2,480 mm outside turning radius support movement through suitable yard and loading areas.
For specific operating conditions, attachments, load requirements, and regional compliance, confirm the final configuration with the supplier before purchase.
Key Features
Economical Diesel Configuration
The SCC25 focuses on the core requirements of a 2.5 ton outdoor forklift, providing a practical configuration for routine material-handling operations.
2,500 kg Rated Capacity
The rated capacity is 2,500 kg at a 500 mm load centre, suitable for a range of palletized and packaged industrial loads within the applicable load chart.
3,000 mm Standard Lift Height
The standard mast provides a 3,000 mm lift height for routine loading, unloading, and stacking tasks.
Four-Cylinder Diesel Engine
The QC490BPG engine is listed with 2,540 cc displacement, 39 kW rated output at 2,650 rpm, and 160 N·m rated torque at 1,980 rpm.
Pneumatic Industrial Tires
The SCC25 uses 7.00-12-12PR front tires and 6.00-9-10PR rear tires, supporting operation on suitable outdoor industrial surfaces.
Practical Yard Mobility
The 1,160 mm overall width, 1,650 mm wheelbase, and 2,480 mm outside turning radius provide practical dimensions for yard operations and loading areas.
19 km/h Travel Speed
The listed maximum unloaded travel speed is 19 km/h, supporting movement between loading, unloading, and storage locations.
Hydraulic Attachment Capability
The specification sheet lists 17.5 MPa operating pressure for attachments. Hydraulic flow, attachment compatibility, and residual capacity should be confirmed for the selected configuration.
| Parameter | Specification |
|---|---|
| Model | SCC25 |
| Power Type | Diesel |
| Rated Capacity | 2,500 kg |
| Load Centre | 500 mm |
| Lift Height | 3,000 mm |
| Engine | QC490BPG, 39 kW |
| Travel Speed | 19 km/h |
| Maximum Gradeability | 20% |
| Overall Width | 1,160 mm |
| Turning Radius | 2,480 mm |
