SH130 1.3 Ton Wheel Loader with 74 kW Engine & 0.55 m³ Bucket
Strong Loading Capacity
With a 1,300 kg rated operating load and 0.55 m³ bucket, the SH130 handles daily loading and material transport tasks efficiently.
Powerful 74 kW Performance
Its 74 kW rated power provides strong and reliable performance for demanding construction, agricultural and material-handling operations.
High Working & Dumping Reach
A 4,070 mm maximum operating height, 2,500 mm dumping height and 700 mm dumping reach enable efficient truck loading and material stacking.
Efficient Hydraulic System
With 75 L/min rated flow and up to 140 L/min high flow, the hydraulic system supports responsive operation and productive working cycles.
Built for Versatile Applications
With a 3,550 kg operating weight and durable 12-16.5 tires, the SH130 is ready for construction, agriculture, landscaping and material yards.
The SH130 is a versatile wheel loader engineered for efficient material handling, loading and lifting operations. With a 1,300 kg rated operating load, 74 kW rated power and 4,070 mm maximum operating height, it delivers the performance needed for demanding daily applications while maintaining a compact and maneuverable working profile.
Confident Loading Performance
The 1,300 kg rated operating load gives the SH130 the capability to handle demanding loading, lifting and material-handling tasks across construction, agriculture, landscaping and material yards.
Power for Demanding Work
With 74 kW of rated power, the SH130 delivers the strength needed for efficient loading, lifting and material transport, even in demanding working conditions.
Reach Higher. Load Smarter.
A 4,070 mm maximum operating height and 2,500 mm dumping height provide the reach needed for efficient truck loading, material stacking and elevated handling operations.
Fast, Responsive Hydraulic Performance
The hydraulic system delivers 75 L/min rated flow and up to 140 L/min high flow, supporting responsive attachment operation, efficient working cycles and consistent productivity.
| Key Specification | Value |
|---|---|
| Model | SH130 |
| Rated Operating Load | 1,300 kg |
| Rated Power | 74 kW |
| Bucket Capacity | 0.55 m³ |
| Operating Weight | 3,550 kg |
| Max. Operating Height | 4,070 mm |
| Max. Dumping Height | 2,500 mm |
| Dumping Reach | 700 mm |
| Hydraulic Flow | 75 L/min |
| High Hydraulic Flow | Up to 140 L/min |
| Overall Width | 1,880 mm |
Designed Around Real Working Conditions
High Dumping Height 2,500 mm
Designed to provide practical clearance for loading trucks, containers and material piles.
Extended Dumping Reach 700 mm
Provides additional forward reach during dumping operations for greater flexibility on the jobsite.
Maximum Operating Height 4,070 mm
Enables efficient handling and stacking of materials at elevated working positions.
40° Maximum Dumping Angle
Supports efficient bucket discharge and helps improve material unloading efficiency.
One Loader. Multiple Applications.
Construction Sites
Handle soil, sand, aggregate and other bulk materials for everyday construction operations.
Agriculture & Farming
Load and transport soil, feed, grain and other agricultural materials around farms and storage areas.
Landscaping
Move soil, mulch, gravel and landscaping materials efficiently across job sites.
Material Yards
Designed for loading, stacking and transferring bulk materials in yards and storage facilities.
Municipal & Road Maintenance
Suitable for general material handling and maintenance operations where compact equipment and reliable loading performance are required.
